1 / 3
| Code | SH-3T | SH-5T |
| Loading | 3T | 5T |
| Working Height | 850mm | |
| Working Stroke | 500mm | 600mm |
| Transformer Body Size | Length: 700–1600mm | Width: 200–900mm | Height: 200–900mm | |
| Lifting Speed (Adjustable) | V = 40mm/s | |
| Working Pressure | P = 14MPa | |
Features a positioning accuracy of ±0.05mm, ensuring precise alignment of amorphous core body components during assembly. This avoids misalignment-induced magnetic loss.
Comes with a scratch-resistant worktop and adjustable soft supports. It effectively prevents scratches, cracks, or deformation of fragile amorphous alloy sheets.
Adapts to various sizes and structures of amorphous core bodies. No need for frequent equipment modification, improving adaptability to diverse production demands.
Streamlines manual assembly workflows by optimizing component positioning. It minimizes human errors and complies with industrial quality standards.
Widely used in assembling core bodies for distribution transformers and power transformers. It precisely positions laminations to avoid magnetic loss, supporting high-energy-efficiency performance.
Ideal for high-frequency inductors in new energy vehicle systems and power reactors. Its scratch-resistant design protects fragile materials for stable electromagnetic characteristics.
Adapts to high-precision assembly needs of motor cores and current transformers. Meets unique structure requirements of special devices for high-performance standards.
