| Code | SH-300 | SH-400 | SH-600 | SH-900 |
| Shearing width | 40-300mm | 40-440mm | 60-640mm | 90-920mm |
| Shearing length | 300-2000mm | 300-2500mm | 400-3500mm | 500-5000mm |
| Shearing thickness | 0.20-0.35mm | |||
| Shearing length precision | ±0.1mm | |||
| Slitting burr | ≤0.02mm | |||
| Shearing angle precision | ±0.025° | |||
| Slitting width error | ±0.025° | |||
| Max feeding speed | 250m/min | 200m/min | ||
| Sorting out method | Automatic sorting out | |||
| Locating method | Center locating | |||
| Installing capacity | 25kw | 30kw | 35kw | 70kw |
Adopts advanced CNC control system, achieving a cutting accuracy of ±0.1mm. It ensures the flatness and dimensional consistency of silicon steel sheets.
Features high-speed cutting operation and integrated automatic feeding, positioning, and stacking, improving efficiency by over 30%.
Optimized for both GO and NGO silicon steel sheets. Flexible adjustment of parameters to meet diverse size requirements.
Meets international standards such as IEC and ASTM. Intelligent fault early-warning function ensures long-term reliability.
Used for cutting silicon steel sheets into stator and rotor core laminations. The high precision ensures a tight fit, reducing magnetic loss and improving energy efficiency for household and EV motors.
Processes sheets into transformer core laminations for power and distribution transformers. Helps reduce core loss, meeting modern energy-saving requirements.
Supplies precision-cut sheets for power inductors, reactor cores, and air conditioner compressors, matching the trend of miniaturization and high-efficiency.
