| Technical Parameters | |
| Processing Speed | 0-50m/min (Adjustable) |
| Processing Precision | ±0.1mm |
| Max. Foil Width | 300mm (Customizable) |
| Max. Wire Diameter | 0.1-2.0mm |
| Power Supply | 220V/380V 50/60Hz (Optional) |
| Power Consumption | ≤3kW |
| Machine Dimension | 1800×800×1500mm (Approx.) |
| Net Weight | 500kg (Approx.) |
| Performance Features | |
| Integrates foil and wire processing functions, realizing one-machine multi-purpose. | |
| Equipped with high-precision servo control system, ensuring stable and accurate operation. | |
| Adopts human-machine interface (HMI) for easy parameter setting and operation. | |
| Compact structure, saving workshop space and reducing production line layout cost. | |
| Structural Configuration | |
| Main Body | High-quality steel frame, anti-rust and durable. |
| Control System | PLC + Touch Screen |
| Driving System | Servo Motor |
| Feeding Mechanism | Automatic Tension Control Feeder |
Realizes one-machine multi-purpose, integrating foil and wire processing functions. Eliminates the need for separate equipment and material transfer, significantly improving production efficiency by 30%+.
Reduces initial equipment investment and subsequent maintenance costs. Compact structure saves 40%+ workshop space compared to separate machines, optimizing production line layout.
Equipped with high-precision servo control system, ensuring processing precision of ±0.1mm. Stable operation avoids material waste caused by deviation, guaranteeing consistent product quality.
Adopts HMI touch screen, enabling one-key parameter setting and intuitive operation. Reduces training time for operators, lowering labor intensity and human error rate.
Compatible with various materials (aluminum foil, copper wire, etc.) and specifications. Flexible adjustment of processing parameters to meet diverse needs in packaging, electronics, printing industries.
The machine is a dedicated equipment for transformer coil manufacturing, integrating foil winding and wire processing functions. It mainly serves the key links of coil conductor forming, lead wire connection and shielding layer processing.
2.1 Power Distribution Transformer Coils: Realizes integrated processing of foil windings and lead wires. Adapts to medium and low voltage distribution transformer coils (10kV and below).
2.2 Power Transformer Coils: Used for large-capacity power transformer coil windings. Accurately controls tension to avoid wrinkles of foil and deformation of wire.
2.3 High-Frequency Transformer Coils: Suitable for switching power supply transformers. Realizes precise matching of thin foil (≤0.1mm) and fine wire (≤0.5mm).
