| Code | SHZL-50N / SHZL-100N |
| Max Load Capacity | 100 kg |
| Tray Height | ≤ 400 MM |
| Tray Diameter | ≤ 500 MM |
| Moving Length | ≤ 800 MM |
| Tension Control Range | 50 N – 5000 N (adjustable in 1 N increments) |
| Tension Accuracy | ±1% of set value (closed-loop control via tension sensor) |
| Wire Adaptation – Round Wire | Diameter: 0.5 mm – 50 mm (enameled copper, enameled aluminum wire) |
| Wire Adaptation – Flat Wire | Cross-section: 5 mm × 10 mm – 20 mm × 50 mm (paper-insulated, bare flat copper) |
| Wire Feeding Speed | 0.5 m/min – 10 m/min (stepless speed regulation) |
| Speed Stability | ±0.2 m/min (avoids wire jitter or uneven arrangement) |
Stably adjust the cable pay-off tension, avoiding abrasion, deformation, or breakage of cables caused by uneven tension.
Made of high-strength and corrosion-resistant materials to withstand heavy loads in complex construction sites.
Equipped with an anti-slip base and real-time fine-tuning components to reduce operational risks.
Compatible with multiple high-voltage cable specifications, eliminating the need for frequent equipment replacement.
Reduces cable jamming and rework, shortening the construction cycle for power transmission projects.
Controls conductor tension to ensure coil tightness for 10kV–1000kV power transformers, supporting round enameled and flat paper-wrapped wires.
Ideal for epoxy-cast coils for dry-type transformers and rectifier transformers, ensuring insulation isolation and preventing wire warping.
Achieves balanced tension control for simultaneous winding of 2–8 conductors, meeting low-loss requirements of large transformers.
Integrates with winding and cutting machines for an automated process, including data recording and abnormality warnings.
